Built to handle Australia's toughest conditions, every specification has been engineered for reliability, comfort, and long-term value. Review the full build sheet below.
External Body Length 5925mm
External Length (End Coupling to Outer Bumper Bar: Underslung spare wheel) 8325mm
External Height (Ground to Top of AC Unit) 3200mm
External Width includes all protruding fixtures 2500mm
Internal Height 2010mm
Internal Width 2285mm
ATM 3500kgs
Alko Engineered Wheel Arch Designed Infill Truss Chassis - Galvanized
Extended Aframe (steel 6" x 2") C450 1800mm
Truss Main Bearers Top: 75x50 Grade C350
Truss Main Bearers Bottom: 50x50x3mm Grade C350
Aluminium Wall Frame
Full Piece Composite Roof: 5 Colour Options
22mm XPS Moisture Resistant Insulation between Aluminium Wall Frames
Poly Honey Comb Heavy Duty Flooring 38mm Plus Fibreglass skin
30mm One Piece XPS Insulated CNC Pre-Fabricated Roof
Aluminium Composite Panel: 5 Colour Options
Cruisemaster Tandem XT 3.7T ATM Coil Suspension with 12" Electric Brakes
DO35 Coupling
265/75 R17 All Terrain Tyres on Silver/Black Rims Includes One Spare Wheel
Black Checker Plate, approx 750mm on sides
Printed Decals Choice of 5 colours
Picnic Table
External TV Box
External Awning with Mid roller support
Double Manual Entry Step
Entry Door Grab Handle with Light
Galvanized Bumper Bar 3 ARM 45 DEG 46" STD
Underslung Spare Wheel (at the Aframe)
Alko 8" Jockey Wheel
Full Width Tunnel Boot
Checker Plate Toolbox with Double Sliders and Opening Top Lid
Milenco Dust Reduction Antenna
Jerry Cans x 2
Fusion Panel Speaker Outdoor plus Mounting Bracket, with SRX400 Marine Stereo
Safety Dave RV Dash Kit (6" Dash + Mini Square Camera 92 Degree AHD Black)
